3-DAY INTERNATIONAL ONLINE SEMINAR

Echometer provided an additional FREE online training opportunity to our customers.

Three topics presented over the course of the three-day training event.

Access the recorded sessions using the links below:

DAY 1  -  Fluid Levels

DAY 2  -  Dynamometer

DAY 3  -  Gas Lift/Gas Wells/Plunger Lift




Session 23 Dec 2nd 2020 Identifying Holes in Tubing on Sucker Rod Lifted Wells

Session 23:  When an operating Sucker Rod lifted well is found to have no production to surface, then a recommended practice is to shoot a fluid level down the casing annulus and also shoot a fluid level down the tubing.  Analysis of the acquired acoustic data is used to determine such things as: If there is a hole in the tubing.  Show ineffective pump operation with tubing shots acquired at uniform time intervals, where “pumping up” the tubing occurs too slowly. Require additional tubing back-pressure, since tubing liquid was unloaded from too much gas produced through the pump and up the tubing. Down tubing fluid levels is an effective troubleshooting technique. Fluid level shots, in conjunction with high speed tubing pressure data and dynamometer test provides the operator with enhanced troubleshooting capability to identify a hole in the tubing.  A sudden drop in production in a sucker rod pumped well may be caused by the HIT.

   PDF Documentation Bundle    TAM Examples





Session 22 Nov 11th 2020 Motor Power-Current-Voltage Measurements and Analysis

Session 22:  High‐frequency motor power‐current‐voltage measurements are used to analyze the electrical and  mechanical  performance  of  pumping  units.  ​TAM Software in receives and analyzes the data to determine power usage, power generation, pumping unit balance, gear box upstroke and downstroke torques, motor loadings, and power line loss.  Power line loss is an analysis performed to analyze the power line loss between the electrical system and the pumping unit motor.  The counter‐weight movement for gear box balance is determined easily without use or knowledge of the pumping unit dimensions.

   PDF Documentation Bundle    TAM Examples     TAM Power Feature Manual





Session 21 Oct 14th 2020 Over Travel Occurs on Up and Down Stroke: Benefits of High Speed and Resolution Data Acquisition

Session 21:  The surface dynamometer card down or up slope from left to right defines an "Over travel Card" or an “Under travel Card”. Rod stretch creates the under travel cards.  Pumping fast or high plunger velocities created by the sudden release of load creates over travel cards. Pump sudden load changes and resulting velocity changes occurring along the sucker rod string away from the beginning of the up stroke or the beginning of the down stroke cause an increase in equipment down hole failures.  The sudden load and velocity change results in rod on tubing contact, increased rod on tubing wear, and impact loads.  Often delayed closing or delayed opening of the standing or traveling valve occurs during sucker rod pumping of gassy unconventional wells. High speed and high resolution data will be used to identify how the pump is performing and to clearly analyze the severity of sudden impact loads. ​

   PDF Documentation Bundle    TAM Examples





Session 20 Sept 30 2020 Sucker Rod Pumping System Design - QRod 3.1

Session 20:  QRod is the most widely used Sucker Rod Pumping design program. This program displays results in any system of units and uses a damped wave equation to accurately predict the surface and pump dynamometer loads, gearbox torque and pump capacity, with minimum input. QRod’s objective is to help the beam pumping system designer implement state of the art design technology without getting buried with details. Changing parameters such as tubing anchor, stroke length, stroke rate, or pump diameter is immediately seen in # #oilgas dynamically updated plots. Patterson equation in Pump Slippage Calculator allows specifying pump clearance to determine the pump slippage, pump efficiency and to predict the net pump displacement. This and other QRod features will be discussed during the presentation.

   PDF Documentation Bundle    TAM and QRod Examples    QRod 3.1 Installer





Session 19 Sept 23 2020  Conventional and Bypass Plunger Performance: Advantages of Tracking a Plunger

Session 19:  Plunger Lift operations can be difficult to optimize due to lack of knowledge of tubing pressure, casing pressure, bottomhole pressure, liquid accumulation in the tubing and location of the plunger.  Knowing the plunger position in the tubing helps the operator to understand the operation of the plunger system in order to optimize the removal of liquids and gas from the well.Plunger Lift operations can be difficult to optimize due to lack of knowledge of tubing pressure, casing pressure, bottomhole pressure, liquid accumulation in the tubing and location of the plunger.  Knowing the plunger position in the tubing helps the operator to understand the operation of the plunger system in order to optimize the removal of liquids and gas from the well.

   PDF Documentation Bundle    TAM Examples



Session 18 Sept 16 2020  Downhole Gas Separators

Session 18:  Many Sucker Rod Lifted wells having gas interference operate with less than 30% liquid pump fillage. Often, the main cause of inefficient operations is either NO downhole gas separator or one that is inefficient. To identify gas interference as the cause of this problem, obtain an acoustic liquid level test which indicates a high gaseous liquid column above the pump intake and analysis of the dynamometer data will indicates incomplete pump fillage. To correct your pump's gas interference problem, install a gas separator below the pump. Correct design results in complete pump fillage, if sufficient liquid inflow into the wellbore is available.

   PDF Documentation Bundle    TAM Examples   Gas Separator Presentation    Gas Separator Simulator Instructional Video    Gas Separator Simulator Software





Session 17 Sept 9 2020  TAM Software Dynamometer Features and Navigation

Session 17:  Learn the TAM Software Dynamometer features. During this session, we navigate the TAM Dynamometer buttons and features, and demonstrate the "hidden" tools are resources available for dynamometer data analysis. If you are new to the TAM software, or interested in a TAM navigation overview, please join us for this session.

   PDF Documentation Bundle    TAM Examples





Session 16 Sept 2 2020  The Three Main Causes of Incomplete Pump Fillage

Session 16:  Incomplete pump fillage is often associated erroneously with a “pumped-off well”, meaning that the pump displacement exceeds the production capacity of the reservoir, ignoring the fact that there are two other causes of partial liquid fillage: gas interference and the presence of a flow restriction or excessive pressure drop at the pump intake. The result of a misdiagnosis is to incorrectly set the mode of operation of pump-off controllers, variable speed drives or timers thereby loosing significant amounts of production. This Ask (((ECHOMETER))) presentation describes the three causes of incomplete pump fillage, presents several sets of field data for the various cases, discusses how to combine dynamometer and fluid level records to correctly identify the source of the problem and presents recommendations for possible solutions.

   PDF Documentation Bundle    TAM Examples   Gas Separator Simulator





Session 15 Aug 26 2020 TAM Software Liquid Level Features and Navigation

Session 15:  If you are new to the TAM software, or if you are interested in an overview of the tools and resources available to you for analyzing data, please join us for this session. We will cover software navigation, analysis tool locations and features, and answer any TAM features questions you may have.

   PDF Documentation Bundle    TAM Examples





Session 14 Aug 19 2020 Best Practices for Shooting Fluid Levels on Difficult Wells

Session 14:  Best practices should become methodical, intentional practices. During this session, we discuss best practices for installing equipment, determining what pressure differential to use on the gas gun, knowing when a quality fluid level shot has been acquired, and also tips for analyzing difficult fluid levels shots.

   PDF Documentation Bundle       TAM Examples





Session 13 Aug 12 2020 Echometer Equipment Maintenance and Troubleshooting

Session 13:  This week we take a side step from analysis discussion and focus our time on equipment maintenance and troubleshooting. We will have one of our wireless technicians on hand to answer questions and provide some recommendations for repair, maintenance and cleaning. Great session for field personnel working with Echometer equipment.

   PDF Documentation Bundle





Session 12 Aug 5 2020 Net Torque Acting on a Pumping Unit Gearbox

Session 12:  There are three Methods to determine the net torque loadings on a pumping unit’s gearbox. Field cases of applying all three methods are presented along with the pros and cons of using each method. 1. Use input motor power, motor and drive efficiencies and the pumping unit speed. 2. Use surface dynamometer card and torque factors together with counterbalance moments determined from static counter balance effect, CBE, test. 3. Use surface dynamometer card and torque factors together with counterbalance moments from the crank and weights.

   PDF Documentation Bundle       TAM Data Set       Q&A





Session 11 July 29 2020 Shut-In Fluid Levels Part 2

Session 11: The discussion continues on the benefits of shooting fluid levels on shut-in wells, SBHP calculations on gas wells, and why the SBHP is important to better understand a well’s performance and producing conditions. Emphasis on SBHP of flowing wells, gas wells, gaslift wells, plunger lift wells. Presented by Dieter Becker, Dr. Tony Podio, and Gustavo Fernandez.

   PDF Documentation Bundle       TAM Data Set





Session 10 July 22 2020 Liquid Level Workshop

Session 10: During this Liquid Level Workshop, we discuss recommendations for quality data acquisition, the three methods for depth determination (Automatic Collar Count, Downhole Markers, Acoustic Velocity), followed by what to look for when analyzing a shot using the examples in our downloadable Liquid Level Workbook and TAM data sets. Practical application of liquid level analysis techniques will be demonstrated. Presented by Lynn Rowlan, Tony Podio, Carrie-Anne Taylor and Gustavo Fernandez

   PDF Documentation Bundle       LL Workbook and TAM Data       Q&A





Session 9 July 15 2020 Dynamometer Workshop

Session 9: Dynamometer acquisition using the Polished Rod Transducer (PRT) and the Horseshoe Load Cell is discussed. An understanding of how to know when quality data is acquired is the first essential step in quality data analysis. Following the acquisition discussion, several dynamometer cards and data sets are presented using the Dynamometer Workbook and data sets below. Practical application of the analysis information covered in past Ask Echometer sessions will be demonstrated. Presented by Lynn Rowlan, Tony Podio, Carrie-Anne Taylor and Gustavo Fernandez.

   PDF Documentation Bundle       DYN Workbook and TAM Data       Q&A







Session 8 July 8 2020 Troubleshoot and Analyze Sucker Rod Wells Using Reference Load Lines and Pressure Annotations

Session 8 Pump cards have three load reference lines 1) Zero Load line, 2) Fluid Load line from Fluid Level, Fo, calculated using the pump intake pressure determined from an acoustic Fluid Level measurement, and 3) Maximum Fluid Load, Fo max, line calculated by setting the pump intake pressure equal to zero. Certain downhole pump problems can be recognized based on the location of the pump card loads with respect to the three load reference lines. When there is no apparent pump action the load value of the flat pump card can be used to determine if there is 1) a shallow rod part, 2) a deep rod part or traveling valve, TV, is stuck open, 3) Tubing is dry of well fluids, 4) the standing valve, SV, is stuck open or 5) the SV is stuck closed with no fluid is entering the pump. Typical pump card loads plot near zero load line on the down stroke and the loads plot near Fo from Fluid Level load line on the upstroke.  Presented by  Lynn Rowlan.

   PDF Documentation Bundle       TAM Example Files       Q&A







Session 7 July 1 2020 Acoustic Fluid Levels to Analyze and Troubleshoot Gas Wells

Session 7 Examples of acoustic tests are presented, where the test are performed on shut-in or flowing above or below critical flow rate gas wells with or without surfactant treatments acquired down the tubing or the tubing/casing annulus.  Techniques for acoustic liquid level analysis are discussed for gas wells where unusual conditions exist such as very shallow liquid levels, very deep liquid levels, noisy wells, high bottomhole temperature, and low or high surface pressures. Presented by  Lynn Rowlan.

   PDF and Excel Documentation Bundle       TAM Example Files       Q&A





Session 6 June 24 2020 How Much Liquid Does My Sucker Rod Pump Pump?

Session 6 Lynn explains how gas interference and pump slippage is used to adjust the effective plunger stroke to deterine the amount of stock tank liquid contained in one pump stroke.  Presented by  Lynn Rowlan.

   Presentation PDF     TAM Examples and Documentation Bundle   Q&A





Session 5 June 17 2020 Acoustic Techniques for Gas-Lift Wells

Session 5 presents benefits of shooting fluid levels on gas-lift wells, analyzing gas-lift fluid level shots, tips for difficult fluid level shots with multiple reflections, and an introduction to the Dual Shot method for identifying leaky gas-lift and check valves. Presented by Carrie-Anne Taylor and Lynn Rowlan.

   Presentation PDF     Download TAM Example Files





Session 4 June 10 2020 Fluid Levels on Shut-In Wells in Today's Environment - Part 1

Session 4 presents the benefits of shooting fluid levels on shut-in wells to obtain SBHP (static bottomhole pressures). Presented by Dieter Becker, Dr. Tony Podio and Gustavo Fernandez.

   Presentation PDF     Download TAM Example Files







Session 3 June 3 2020 Introduction to Plunger Lift

Session 3 introduces the concept of plunger lift, shows how to track plungers, use data collected to identify problems, and reviews plunger lift data acquisition. Presented by Lynn Rowlan.

   Presentation PDF     Download TAM Example Files





Session 2 May 27 2020 Examples of Forces NOT Accounted for by the Wave Equation

Session 2 we discuss analyzing dynamometer data that shows different types of Mechanical Friction. Presented by Lynn Rowlan.



Presentation PDF     Download TAM Example Files









Session 1 May 20 2020 Direction of Kick on Acoustic Traces

Session 1 covers interpreting an acoustic trace, understanding the direction of kick, finding holes in tubing, and different analysis methods for determining an accurate distance to the liquid level. Presented by Lynn Rowlan.

  Presentation PDF    Download TAM Example File
